| 472849 | WINDLASS V. X4 CRO G+D 2700W/24V 14mm | 187334 | Included in package | 14 mm | – | – | 12 m/min | 28 m/min | 2400 kg | 2700 W | 85 kg | 24 V | CW | With Drum | 170 | 530 |
| 473007 | WINDLASS V. X4 CRO G+D 2300W/24V 12-13DIN766 | 187333 | Included in package | 12 mm, ISO 4565 / 13 mm, DIN 766 | – | – | 12 m/min | 25 m/min | 2000 kg | 2300 W | 82 kg | 24 V | CW | With Drum | 160 | 500 |
| 476292 | WINDLASS V. X4 CRO G+D 2300W/24V 14mm | 187333 | Included in package | 14 mm | – | – | 12 m/min | 25 m/min | 2000 kg | 2300 W | 82 kg | 24 V | CW | With Drum | 160 | 500 |
| 600073 | WINDLASS V. X4 CRO G+D 2300W/24V 10 3/8 HT | 187333 | Included in package | 10 mm, ISO 4565 | – | – | 12 m/min | 25 m/min | 2000 kg | 2300 W | 82 kg | 24 V | CW | With Drum | 160 | 500 |
| 600074 | WINDLASS V. X4 CRO R. G+D 2300W/24V 12-13DIN766 | 187333 | Included in package | 12 mm, ISO 4565 / 13 mm, DIN 766 | – | – | 12 m/min | 25 m/min | 2000 kg | 2300 W | 82 kg | 24 V | CCW | With Drum | 160 | 500 |
| 600075 | WINDLASS V. X4 CRO G+D 2700W/24V 12-13DIN766 | 187334 | Included in package | 12 mm, ISO 4565 / 13 mm, DIN 766 | – | – | 12 m/min | 28 m/min | 2400 kg | 2700 W | 85 kg | 24 V | CW | With Drum | 170 | 530 |
| 600076 | WINDLASS V. X4 CRO CCW G+D 2700W/24V 12-13DIN766 | 187334 | Included in package | 12 mm, ISO 4565 / 13 mm, DIN 766 | – | – | 12 m/min | 28 m/min | 2400 kg | 2700 W | 85 kg | 24 V | CCW | With Drum | 170 | 530 |
| 601002 | WINDLASS V. X4 CRO CCW 2300W/24V 1/2 HT | 187333 | Included in package | ½ HT | – | – | 12 m/min | 25 m/min | 2000 kg | 2300 W | 72 kg | 24 V | CCW | Low Profile | 160 | 500 |
| 601003 | WINDLASS V. X4 CRO CCW 2300W/24V 7/16 HT | 187333 | Included in package | 7/16 HT | – | – | 12 m/min | 25 m/min | 2000 kg | 2300 W | 72 kg | 24 V | CCW | Low Profile | 160 | 500 |
| 601142 | WINDLASS V. X4 CRO R. 2300W/24V 12-13DIN766 | 187333 | Included in package | 12 mm, ISO 4565 / 13 mm, DIN 766 | – | – | 12 m/min | 25 m/min | 2000 kg | 2300 W | 72 kg | 24 V | CCW | Low Profile | 160 | 500 |
| 601143 | WINDLASS V. X4 CRO 2300W/24V 14mm | 187333 | Included in package | 14 mm | – | – | 13 m/min | 25 m/min | 2100 kg | 2300 W | 72 kg | 24 V | CW | Low Profile | 160 | 500 |
| 601150 | WINDLASS V. X4 CRO R. G+D 2300W/24V 14mm | 187333 | Included in package | 14 mm | – | – | 12 m/min | 25 m/min | 2000 kg | 2300 W | 82 kg | 24 V | CCW | With Drum | 160 | 500 |
| 601159 | WINDLASS V. X4 CRO R. 2700W/24V 12-13DIN766 | 187334 | Included in package | 12 mm, ISO 4565 / 13 mm, DIN 766 | – | – | 12 m/min | 28 m/min | 2400 kg | 2700 W | 75 kg | 24 V | CCW | Low Profile | 170 | 530 |
| 601165 | WINDLASS V. X4 CRO 2700W/24V 10DIN766 | – | Included in package | 10 mm DIN 766 3/8’’ BBB | – | – | 13 m/min | 28 m/min | 2500 kg | 2700 W | 75 kg | 24 V | CW | Low Profile | 170 | 530 |
| 601167 | WINDLASS V. X4 CRO G+D 2700W/24V 10 3/8 HT | – | Included in package | 10 mm ISO 4565 3/8’’ HT | – | – | 12 m/min | 28 m/min | 2400 kg | 2700 W | 85 kg | 24 V | CW | With Drum | 170 | 530 |
| 601175 | WINDLASS V. X4 CRO R. G+D 2700W/24V 14mm | – | Included in package | 14 mm | – | – | 12 m/min | 28 m/min | 2400 kg | 2700 W | 85 kg | 24 V | CCW | With Drum | 170 | 530 |
| 601203 | WINDLASS V. X4 CRO R. 2200W/400V 12-13DIN766 | – | Switchboard available separately | 12 mm, ISO 4565 / 13 mm, DIN 766 | – | – | 16 m/min | 16 m/min | 2200 kg | 2200 W | 73 Kg | 400 V | CCW | Low Profile | – | 595 |
| 601204 | WINDLASS V. X4 CRO 2200W/400V 12-13DIN766 | – | Switchboard available separately | 12 mm, ISO 4565 / 13 mm, DIN 766 | – | – | 16 m/min | 16 m/min | 2200 kg | 2200 W | 73 Kg | 400 V | CW | Low Profile | – | 595 |
| 601208 | WINDLASS V. X4 CRO R. G+D 2200W/400V 14mm | – | Switchboard available separately | 14 mm | – | – | 16 m/min | 16 m/min | 2200 kg | 2200 W | 80 kg | 400 V | CCW | With Drum | – | 595 |
| 601209 | WINDLASS V. X4 CRO G+D 2200W/400V 14mm | – | Switchboard available separately | 14 mm | – | – | 16 m/min | 16 m/min | 2200 kg | 2200 W | 80 kg | 400 V | CW | With Drum | – | 595 |
| 602360 | WINDLASS V. X4 CRO R. 2300W/24V 14mm | 187333 | Included in package | 14 mm | – | – | 13 m/min | 25 m/min | 2100 kg | 2300 W | 72 kg | 24 V | CW | Low Profile | 160 | 500 |
| 602361 | WINDLASS V. X4 CRO G+D HYD/ 12-13DIN766 | – | – | 12 mm, ISO 4565 / 13 mm, DIN 766 | 32 lt/min | 200 bar | 16 m/min | 16 m/min | 2500 kg | Hydraulic-8cc | 60 kg | – | CW | With Drum | – | 650 |
| 602362 | WINDLASS V. X4 CRO G+D HYD/ 14mm | – | – | 14 mm | 32 lt/min | 200 bar | 16 m/min | 16 m/min | 2500 kg | Hydraulic-8cc | 60 kg | – | CW | With Drum | – | 650 |
| 602363 | WINDLASS V. X4 CRO R. G+D HYD/ 12-13DIN766 | – | – | 12 mm, ISO 4565 / 13 mm, DIN 766 | 32 lt/min | 200 bar | 16 m/min | 16 m/min | 2500 kg | Hydraulic-8cc | 60 kg | – | CCW | With Drum | – | 650 |
| 602364 | WINDLASS V. X4 CRO R. G+D HYD/ 14mm | – | – | 14 mm | 32 lt/min | 200 bar | 16 m/min | 16 m/min | 2500 kg | Hydraulic-8cc | 60 kg | – | CCW | With Drum | – | 650 |
