Philippi 700125511 – Off/On/1+2 Battery Main Switch BHS 330 (2-pole)

Description

The Philippi 700125511 – Off/On/1+2 Battery Main Switch BHS 330 (2-pole) features On/Off and Emergency Parallel Switching for two poles, supporting a continuous current of 350 A per channel and a peak current of 700 A for 30 seconds per channel. It operates at a maximum voltage of 32 V DC and can be mounted either flush or on the surface. The switch connects via M10 tinned copper terminals, with a maximum tightening torque of 13 Nm, and measures 98 x 98 x 79 mm, requiring a mounting hole with a diameter of 92 mm for behind-panel installation.
