Philippi 700970497 – Tank Measurement Water, Diesel, Petrol (Gobius 4)

Description

Suitable for all tank materials: steel / stainless steel wall thickness 1-3 mm, aluminum wall thickness 2-5 mm, plastic (polyethylene) wall thickness 2-10 mm, glass fiber wall thickness 4-8 mm. The level is shown on the display using 4 LEDs and can also be displayed on analog instruments or the tank monitor TCM 4V. The package includes 3 sensors, a control unit, and an LED remote display. The nominal voltage is 12 V/24 V, with an active current consumption of 40 mA. The output signal ranges from 10-180 ohms, 240-33 ohms, and 4-20 mA. The display dimensions are W 60 x H 60 x D 3 mm, while the sensor dimensions are H 26 mm and Ø 70 mm.
