Philippi 71000306 – Digital shunt 300A SHX 300-L

Description

The Philippi 71000306 Digital Shunt 300A SHX 300-L, identified as Type Philippi SHL 312, is an active measurement shunt designed for direct connection to the PBUS. It excels in precisely recording currents from individual consumers or various charging sources such as solar cells, wind generators, alternators, or hydrogenerators. The SHL 312 facilitates the display of energy distribution on the DC energy monitor of the PSM. Featuring an M12 connection cable for seamless integration with the PBUS, it boasts a current carrying capacity of 300 A (600 A for 1 min, 1500 A for 0.5 s) and supports nominal voltages of 12 V, 24 V, 36 V, and 48 V. With a current consumption of 6 mA (stand-by 2 mA @ 12V) and an operating voltage range of 8 – 60 V, it provides a measuring range spanning from 10 mA to 1500 A. Compact in size, with dimensions of L 118 x B 40 x H 52mm, this digital shunt offers precise and efficient current monitoring for a range of applications.
